UV polarized Skin Dermatology Wood's lamp Exam light KN-9000A

UV polarized Skin Dermatology Wood's lamp Exam light KN-9000A

Brand Kernel
Model KN-9000A
Delivery time 3-5 days after receipt of payment
Supply capacity 50 sets per week

Wood's Lamp Overview
A Wood's lamp is a device that emits ultraviolet (UV) light in the 365 nanometer range and is commonly used by dermatologists to assist in the diagnosis of various pigment and infectious disorders. The examination is performed in a dark room, allowing the Wood's light to shine directly on the affected area for a few seconds and looking for any changes in color or fluorescence. Normal skin does not fluoresce under the light of a Wood's lamp. If a fungal or bacterial infection or pigment disorder is present, Wood's lamp examination can strengthen or lessen the suspicion of a particular diagnosis, based on the color of fluorescence of the affected skin being illuminated. In addition, subtle changes in color may be detected as well.

Email

Who's at risk?

Some of the many skin disorders that can fluoresce under Wood's light examination include the following:

Fungal infections

Bacterial infections

Head lice and nits Erythrasma Porphyria cutanea tarda

Vitiligo

Other pigmentary disorders

Main features

1.Small size,light weight,portable.

2.Adopt UVA light,wavelength 365nm.

3.Thireteen million effective back camera,automatic focus and mannual focus to get more clear view of leision part.

4.Equipped with shaped silicone hood,Better shading effect, users can also clearly observe and take photos in normal natural light environment

5.Rechargeable Li-ion battery supply,wireless operation,easy to carry on travel or vacation.

6.Latest SMD leds,longer life time,more uniform light spots.

7.5'' HD touch GUI screen,more vivid view and simple operation.

8.High-capacity design,can store more than 1000pcs photos,able to expend capacity by extra memory card and transfer photos to computer for frofessional analysis.

9.Set up patient case,record,check and track skin condition development.

10.Adjustable brightness,easy to change according to enviroment light.

11.Set up standard image database,easy to compare with leision site , strengthen or lessen the suspicion of a particular diagnosis.

12.Turned out to a diagnosis report,directly connect to printer,wireless report print.

Technical parameters

UVA wavelength		320nm-400nm（peak 365nm±10nm）
LED type		Much stable and higher intensity SMD LEDS
LED lifetime		≥15000 hours
Output intensity		≥3mW/cm2
Battery supply		DC6~8.4V >0.5A
Battery work time		2 hours
Display		5” HD touch screen
Back Camera effecitive pixels		13000000
Water dust proof		IP22
High-capacity		Store more than 1000pcs picture

Clinical application

FAQ

Do you have a branch office abroad?
Yes，our kernel have set up for 22 years.we have branch company in US and have exclusive agent Germany,Russia,Singapore etc. And have many agency all over the world....more
